Light Emitting Element

1310/1550nmFP-LD,LED

980/1480/1550nm FP-LD

1310/1550nm  DFB-LD

Output Optical Power

(SM Fiber Pigtail)

0.03-0.2mW  for LED

0.5-1.5mW for LD Special
Order

Linewidth

<0.5nm for FP-LD

<0.3nm for DFB-LD

>50nm for LED

Operation Mode

Constant Temperature

&Constant Optical Power

(Constant Current for LED)

Short Term Stability

0.01dB (Constant T , after 30min. Warm up, Time=10min.)

Long Term Stability

0.05dB (T=+/-1°C, after 30min. Warm up,Time=24hr)

Optical Connection

FC/PC

Display

mW, 3 1/2 Digit LCD

Display Accuracy

+/-10%

Operating Temperature

-10°C to +40°C

Storage Temperature

-40°C to +70°C

Power

115V/230V+/-10%,50/60Hz, 15W

Dimension (WxHxD)

6.20"x 2.45"x 7.83" (157mmx 62mmx 199mm)

Weight

2.0 lbs (0.91 kg)
