Home Fiber Cleaver & Stripper >> Cleaver >> Sumitomo FC-6S Genuine Fiber Cleaver,No Copy
Fiber Cleaver & Stripper
Sumitomo FC-6S Genuine Fiber Cleaver,No Copy
Manufacturer:
  Sumitomo
Model:
  FC-6S
Condition:
  New
Availability:
  Yes
Price:
  $450.00
Qty:
Description:

   Feature
The Sumitomo FC-6S high precision cleaver is designed for field use alongside the Sumitomo splicing units. By using a rotating blade for multiple scoring positions enables a blade life of 36,000 cleaves with a cleave angle better than 0.5 degrees. The unit is constructed to be robust and field serviceable and has options such as tripod mount to enable secure platform mounting. The FC-6S is the latest Sumitomo cleaver . Integral to the unit is a cleave length scale which helps facilitate exact lengths during cleaving.

Model
FC-6S
Applicable Fiber
Fiber diameter
125um
Fiber count / size
Single fiber (0.25 & 0.9mm) and up to 12-fiber ribbon
Cleave length
10mm
Typical cleave angle
0.5°
Dimensions / Weight
63(W) x 76(D) x 63(H)mm / 430g (FC-6M/FC-6S)
100(W) x 81(D) x 63(H)mm/480g (FC-6M-C/FC-6S-C)
Blade life
36,000fibers
(1,000fibers x 12 edge positions x 3-step edge height)
Option
Adapter for single fiber : AP-FC6M
(Standard installation with the FC-6S/FC-6S-C)
Offcut collector : CU-FC6
(Standard installation with the FC-6M-C/FC-6S-C)
Blade replacement : FCP-20BL


*1 Fiber holders are requied according to the fiber applied.
*2 Blade is replaceable
   Details
