OMM-3300 Handheld Optical Multimeter
Manufacturer:
  Opticseq
Model:
  OMM-3300
Condition:
  Brand New
Availability:
  20 pcs
Price:
  $480.00
Qty:
Description:

   Feature
OMM-3300 Handheld Optical Multimeter
integrates the functions of an intelligent optical power meter module and of a highly stable light source module in one unit which can perform closed-loop tests by incorporating both modules. Individual regimes of operation can also be manually chosen using menu operation to switch functions. A perfect combination to make your optical fiber tests a lot more convenient.

Features
● Includes all the outstanding functions of handheld intelligent power meter(OPM-300)
● Includes all the outstanding functions of handheld stable light source(OLS-300)
● Switching of the power meter function and that of the light source by menu operation
● Different light sources and power meters can be built into OMM-3300
Applications
● Maintenance in Telecom
● Maintenance CATV
● Test Lab of optical fibers
● Other Fiber Optic Measurements
   Details
Model
OMM-3300
A
B
C
Power Meter + Laser Source (VFL)
Light Source + Power Meter
Light Source + Power Meter + Laser Source (VFL)
Power Meter
Measuring Range(dBm)
-70~+10/-50~+26
Detector type
InGaAs
Uncertainty (dB)
+0.2(5%)
Calibration wavelength (nm)
850,980,1300,1310,1490,1550
Display precision (dB)
0.01
Light Source
Output wavelength (nm)
1310/1550(other optionl)
Measuring Range(dBm)
-30dBm--23dBm
Accuracy
+10 nW(5%)
SM Output Power(dBm)
>= -2dBm
MM Output Power(dBm)
>= -20dBm
Laser Source (VFL)
Wavelength (nm)
650
Output Power (mw)
1,5,10,20,30(optionl)
General Specification
Communication
RS232
Operating Temperature  (oC)
-10~+60
Storage Temperature  (oC)
-25~+70
Battery Operating Time
>15h
Display
2.4TFT LCD
Dimension (mm)
190*100*48
Power Supply
Li battery (9V)
Weight (g)
280
