Applicable fiber

SM(G.652), MM(G.651), DS(G.653), NZDS(G.655), others(including G.657)

Applicable fiber

SM(ITU-T G.652),MM(ITU-T G.651),DS(ITU-T G.653),NZDS(ITU-T G.655)

Diameter of cladding

80 -150μm

Diameter of coating

160 – 900μm

Typical splice loss

SM:0.02dB, MM:0.01dB, DS:0.04dB, NZDS:0.04dB

Return loss

>60db

Fiber cleaved length

10-16mm (coating diameter< 250μm ), 16mm(coating diameter: 250-1000μm )

Splicing program

40 groups

Operate mode

Manual, Automatic

Auto-heating

Available

Typical splicing time

6 seconds

Tube heating time

16 seconds for 60mm and 40mm shrinkable sleeves

Fiber view magnification

250X(X or Y view), 125X(X and Y view)

Viewing method and display

2 CMOS cameras, 5.0 inch color LCD monitor

Storage of splice result

4000 results

Loss evaluation

Available

Tension test

1.8-2.2N

Interface

GUI menu interface, easier operation

Battery capacity

5200mAh Li-battery, typical 250 cycles(splicing and heating),support independent charging

Power supply

Adaptor, input: AC100-240V(50/60HZ),output: DC11-13.5V

Electrode life

More than 4000 ARC discharges, can be replaced conveniently

Terminals

USB 2.0 port, for uploading splice results and upgrading software

Operating condition

Altitude: 0-5000m, Humidity: 0-95%, Temperature: -25℃～+50℃;Wind speed: max 15m/s

Dimension

160mm(L)x136mm(W)x140mm(H)

Weight

2.2kg including battery
