EXFO FTB-200 + FTB-7400E-023B 42/41dB SM OTDR
Manufacturer:
  EXFO
Model:
  FTB-200
Condition:
  Used
Availability:
  1
Price:
  $3,600.00
Description:
.

   Feature
EXFO FTB-200+FTB-7400E-023B-EA,1310/1550nm, 42/41dB.
EXFO FTB-200 + FTB-7300D-234B-EI-VFL, 1310/1550/1625nm, 39/37/39dB.




The FTB-200 is a compact, modular platform designed for multilayer and multimedium testing

Compatible with the following modules

World-renowned FTB-7000 OTDR B/C/D series
● Up to four wavelengths
● Industry's fastest acquisition times
● Shortest dead zones in the industry
● Singlemode and multimode testing

FTB-8120/8130 Transport Blazer Test modules
Available with Next-Gen SONET/SDH hardware
● FTB-8120: DS1/E1 to OC-48/STM-16 interfaces in a single module
● FTB-8130: DS1/E1 to OC-192/STM-64 interfaces in a single module

FTB-8510 Packet Blazer Ethernet Test Module (available in Q2)
● Ethernet-based packet services testing with wire-speed full-duplex 10, 100 or
1000 Mb/s traffic-generation capabilities
● All the T&M functionalities to meet service-level agreements (SLA) with customers

FTB-3930 MultiTest Module (OLTS)
● Fully automated bidirectional loss tests in seconds for up to three wavelengths;
automatic ORL and fiber-length measurements
● Combines 8 functionalitites in a single module.
◎ Loss meter
◎ Power meter
◎ Optical return loss (ORL) meter
◎ Visual fault locator
◎ Multimode and singlemode light sources
◎ Digital talk set
◎ Fiber-length meter

 A fast, powerful, lightweight solution from the industry’s OTDR expert
●Houses any of EXFO’s renowned OTDR configurations
   Tests up to four wavelengths
   Industry’s fastest acquisition times
   Multimode and singlemode testing
   Shortest dead zones in the industry
●Touchscreen and shortkey functionality
●Future-proof connectivity
●Improved productivity
   4-second power-up time
   Faster acquisition, processing and reporting
●Fiber inspection probe (optional)
●Optical power meter and VFL (optional)
   Details
SPECIFICATIONS

Display
Touchscreen, color, 640 x 480 TFT 163 mm (6.4 in)
Interfaces
USB A main
USB B remote
RJ-45 LAN 10/100 Mb/s
Compact Flash
Fiber inspection probe connector port (video)
Storage
Internal (Flash)
USB sticks 1 GB and 2 GB (optional)
Compact Flash cards (optional)
Batteries
Rechargeable Li-Ion
8 h of operation as per Bellcore TR-NWT-001138
Power Supply
AC/DC adapter, input 100-240 VAC, 50-60 Hz, 2 A max, output: 24 VDC, 90 W
Operating  Temperature
—5 °C to 50 °C
Storage Temperature
—40 °C to 70 °C
Relative humidity
0 % to 95 % non-condensing
Size (H x W x D)
322 mm x 197 mm x 96 mm
Weight
3 kg
Vibration
< 1.5 g at 10 Hz to 500 Hz (on three main axes)
Mechanical shock
< 760 mm on six sides and eight main edges (according to GR-196-CORE)
